***Topgunz ROTREX C38R Supercharger Kit***

TopgunZ

The Z1 kit also uses a bypass valve on the wrong side of the intercooler. It sits on top and the hot charge air is coming in from the bottom meaning all of the HOT air coming from the supercharger is constantly being driven through the intercooler soaking it with heat and never giving it a chance to cool off. This is a terrible idea which will look good on the dyno since they let it cool down with the car off then hit it with one pull. On the street/track that intercooler will always be hot.

They also strung that motor out to 8000 rpm on their run which most guys are never going to do so the numbers are there for show...again.

__________________
ROTREX SUPERCHARGER TUNER KITS - $6799/ CUSTOM STILLEN AIR TO AIR KITS -$2100/ 700+ WHP!! WWW.TOPGUNSPEEDWORKS.COM

Spooler

Don't give them any hints. LOL

DarkJak

It's a damn shame more of the stuff they made for their time attack 370z didn't get produced. https://www.youtube.com/watch?v=JwZDloDWhL8

I ran my 370Z with Topgunz kit at autocross and can happily say, with the wastegate setup keeping boost constant through RPMs, it was SUPER easy to drive. Lots of torque out of corners and when I did have some slip, the car was as controllable as it was when NA.
Ended up at 7th fastest out of 94 on a car I haven't driven at autocross in YEARS, on a tire that wasn't a competitive autocross tire (not a super200 tw tire, not always in temp range)
https://www.youtube.com/watch?v=XQIFBq2x7kk

__________________
@stupidtoycars | My track vids
09 7AT|MCS 2WNR|Topgunz Rotrex|Ecutek (Eugene)|Maxxis RC1|Titan-7 TS-5|OSG LSD|Rear Mount Derale Oil Cooler (WIP)+25 Trans Cooler|Fismo|G-LOC R12/R10|Zeta III L|NLR Wing and Splitter|CJM Pan and Fuel Hat|Radium Surge Tank|AP Racing CP9668

SeeThruHead

how does it sound when you're at 1/2 throttle but still decently high rpms?
Lots of BOV hissing?

__________________
My Build thread STH Build Plan Thread
Images too big fix here

FrankEtier

I hear tons of BOV noises on my car, not much on the WG though.

__________________
‘14 Topgunz Speedworks Rotrex Supercharged VR30 7AT 370Z Magma Red.
@liquid.magma

NorthStyle

I'm just waiting on TGZ to copy Soho and release a bypass valve setup; the BOVs always annoyed me, which is part of the reason I never ran them with any of my turbo'd vehicles lol

14Q60awdSPORT

my TPGZ Rotrex SC Setup, at 3k+ rpm on no throttle/low throttle/decel type scenarios the BOV was a constant loud hissing that I found annoying, same with at idle when there was less noises covering it up.

I made a silencer for the BOV that has had zero negative impact to its functionality and dramatically reduced the volume in all scenarios so you really don't hear or notice anything ever now.

DarkJak

If I'm more than a quarter or 1/3 throttle, the BOV stays closed and is quiet. At very low throttle, that's where it opens and is noisy.

__________________
@stupidtoycars | My track vids
09 7AT|MCS 2WNR|Topgunz Rotrex|Ecutek (Eugene)|Maxxis RC1|Titan-7 TS-5|OSG LSD|Rear Mount Derale Oil Cooler (WIP)+25 Trans Cooler|Fismo|G-LOC R12/R10|Zeta III L|NLR Wing and Splitter|CJM Pan and Fuel Hat|Radium Surge Tank|AP Racing CP9668

TopgunZ

Black Friday Deals Are Here!

$500 off all 370Z/G37 Rotrex Supercharger kits! $6499

Dyno - Industry leading 800whp capable
Strip - 1/4 mile world record supercharged 370Z
Track - Super Lap Battle RWD Record holder and Global Time Attack RWD Record holder
Street - Tried and Proven.

__________________
ROTREX SUPERCHARGER TUNER KITS - $6799/ CUSTOM STILLEN AIR TO AIR KITS -$2100/ 700+ WHP!! WWW.TOPGUNSPEEDWORKS.COM

GUTCH

I guess I'm reviving this thread.

I was under the impression that a smaller pulley creates higher top end power but less low end torque.

Averying

A smaller pulley on the SC means that it is spinner faster at all times, so you’ll be building boost at a lower RPM compared to a larger pulley… thus more low end torque. Theoretically this also means you have more boost at high RPM too, but the TSG Rotrex kit opts to bleed off additional boost at higher RPM and have constant boost after some set RPM. This would mostly be to protect the engine.


Sent from my iPhone using Tapatalk

__________________
2009 Sport Touring | Platinum Graphite | GTM Stage 1 Supercharger | BC BR Coilovers | Hotchkis Swaybar | Z1 FUCAs | AME TM-02 Wheels | Z1 2-piece Front Rotors | Z1 Clutch & Flywheel | Invidia Gemini Catback | GTM Resonated Test Pipes

GUTCH

Interesting.

I read or watched somewhere that a smaller pulley while producing more power by spinning faster is harder to spin. Similar to a higher gear on a bike. And that results in less low end torque. Is that incorrect?

For example here's a source: https://www.aimsindustrial.com.au/bl...ey-speed-ratio

phunk

The link in your source accurately states that a smaller driven pulley will turn faster and produce less torque. If you want to overlay this example with a supercharger, the engine is the drive pulley and the supercharger is the driven pulley. So this wouldn't at all imply that the engine torque would be lower with a smaller supercharger pulley.

But if you want to look at further... sure spinning the supercharger faster should increase parasitic load on the engine some, consuming a small additional amount of the engines output. But as we all know, the airflow (thus HP) provided by a supercharger far outweigh the effort it takes to spin the supercharger itself.

__________________

Sr20dehauler

I bought a Innovate PSB-1 gauge and I have an updated EcuTek. Should I exchange the PSB-1 for a SCG-1?

Also, I am only going with innovate because I have the AAM flex fuel kit with the MTX-D gauge. Are there any better gauge options? I'd like to have only 3 gauges for E%, F temp, F press, A/F (ECB-1?), oil temp & press, and boost (controller?).
